铰刀

适用于在结构钢中铰孔。适用于桥梁建造、安装及造船工业。
Taper Shank Car Reamer(ANSI)
order No. size I L
20400001 5/16 2-3/4 5-11/16
20400002 3/8 2-3/4 5-11/16
20400003 7/16 3-1/2 6-15/16
20400004 1/2 4 7-9/16
20400005 9/16 4 7-9/16
20400006 5/8 4-1/2 8-1/16
20400007 11/16 4-1/2 8-13/16
20400008 3/4 5 9-1/2
20400009 13/16 5 9-1/2
20400010 15/16 5 9-1/2





































Tipped Carbide Parallel Machine Reamer
order No. d d1 L
20401001 6 5.6 93
20401002 7 7.1 109
20401003 8 8 117
20401004 9 9 125
20401005 10 10 133
20401006 11 10 142
20401007 12 10 151
20401008 13 10 151
20401009 14 12.5 160
20401010 15 12.5 162
20401011 16 12.5 170
20401012 17 14 175
20401013 18 14 182
20401014 19 16 189
20401015 20 16 195
























Taper Shank Bridge Reamer (ANSI)
order No. size I L
20402001 7/16 4-3/8 8-1/4
20402002 1/2 5-1/8 9
20402003 9/16 5-1/8 9
20402004 5/8 6-1/8 10
20402005 11/16 7-1/8 11-3/4
20402006 3/4 7-3/8 12
20402007 13/16 7-3/8 12
20402008 7/8 7-3/8 12
20402009 15/16 7-3/8 12
20402010 1 7-3/8 12
20402011 1-1/16 7-3/8 12
20402012 1-1/8 7-3/8 12
20402013 1-3/16 7-3/8 12
20402014 1-1/4 7-3/8 12
20402015 1-5/8 7-3/8 12





































Square Shank Morse Taper Reamer (ANSI)
order No. size I L
20403001 0 2-1/4 3-3/4
20403002 1 3 5
20403003 2 3-1/2 6
20403004 3 4-1/4 7-1/4
20403005 4 5-1/4 8-1/2
20403006 5 6-1/4 9-3/4





































Hand Reamer (ANSI)
order No. size I L
20404001 1/8 1-1/2 3
20404002 9/64 1-5/8 3-1/4
20404003 5/32 1-5/8 3-1/4
20404004 11/64 1-3/4 3-1/2
20404005 3/16 1-3/4 3-1/2
20404006 13/64 1-7/8 3-3/4
20404007 7/32 1-7/8 3-3/4
20404008 15/64 2 4
20404009 1/4 2 4
20404010 17/64 2-1/8 4-1/4
20404011 9/32 2-1/8 4-1/4
20404012 19/64 2-1/4 4-1/2
20404013 5/16 2-1/4 4-1/2
20404014 21/64 2-3/8 4-3/4
20404015 11/32 2-3/8 4-3/4
20404016 23/64 2-1/2 5
20404017 3/8 2-1/2 5
20404018 25/64 2-5/8 5-5/8
20404019 13/32 2-5/8 5-5/8
20404020 27/64 2-3/4 5-1/2
20404021 7/16 2-3/4 5-1/2
20404022 29/64 2-7/8 5-3/4
20404023 15/32 2-7/8 5-3/4
20404024 31/64 3 6
20404025 1/2 3 6
20404026 17/32 3-1/8 6-1/4
20404027 9/16 3-1/4 6-1/2
20404028 19/32 3-3/8 6-3/4
20404029 5/8 3-1/2 7
20404030 21/32 3-11/16 7-3/8
20404031 11/16 3-7/8 7-7/8
20404032 23/32 4-1/16 8-1/8
20404033 3/4 4-3/16 8-3/8
20404034 7/8 4-7/8 9-3/4
20404035 1 5-7/16 10-7/8
20404036 1-1/8 5-13/16 11-5/8
20404037 1-1/4 6-1/8 12-1/4
20404038 1-3/8 6-5/16 12-5/8
20404039 1-1/2 6-1/2 13

























Taper Shank Reamer (ANSI)
order No. size I L
20408001 1/4 1-1/2 6
20408002 5/16 1-1/2 6
20408003 3/8 1-3/4 7
20408004 7/16 1-3/4 7
20408005 1/2 2 8
20408006 17/32 2 8
20408007 9/16 2 8
20408008 19/32 2 8
20408009 5/8 2-1/4 9
20408010 21/32 2-1/4 9
20408011 11/16 2-1/4 9
20408012 23/32 2-1/4 9
20408013 3/4 2-1/4 9-1/2
20408014 25/32 2-1/2 9-1/2
20408015 13/16 2-1/2 9-1/2
20408016 27/32 2-1/2 9-1/2
20408017 7/8 2-5/8 10
20408018 29/32 2-5/8 10
20408019 15/16 2-5/8 10
20408020 31/32 2-5/8 10
20408021 1 2-3/4 10-1/2
20408022 1-1/16 2-3/4 10-1/2
20408023 1-1/8 2-7/8 11
20408024 1-3/16 2-7/8 11
20408025 1-1/4 3 11-1/2
20408026 1-5/16 3 11-1/2
20408027 1-3/8 3-1/4 12
20408028 1-7/16 3-1/4 12
20408029 1-1/2 3-1/2 12-1/2





























Square Shank Reamer (ANSI)
order No. size I L
20405001 1/8 1-1/2 3
20405002 3/16 1-3/4 3-1/2
20405003 1/4 2 4
20405004 5/16 2-1/4 4-1/2
20405005 3/8 2-1/2 5
20405006 7/16 2-3/4 5-1/2
20405007 1/2 3 6
20405008 9/16 3-1/4 6-1/2
20405009 5/8 3-1/2 7
20405010 11/16 3-7/8 7-3/4
20405011 3/4 4-3/16 8-3/8
20405012 7/8 4-7/8 9-3/4
20405013 1 5-7/16 10-7/8
20405014 1-1/8 5-13/16 11-5/8
20405015 1-1/4 6-1/8 12-1/4
20405016 1-3/8 6-5/16 12-5/8
20405017 1-1/2 6-1/2 13





























Pin Rramer (ANSI)

order No. size I L
20406001 7/0 13/16 1-13/16
20406002 6/0 15/16 1-15/16
20406003 5/0 1-3/16 2-3/16
20406004 4/0 1-5/16 2-5/16
20406005 3/0 1-5/16 2-5/16
20406006 2/0 1-9/16 2-9/16
20406007 0 1-11/16 2-15/16
20406008 1 1-11/16 2-15/16
20406009 2 1-15/16 3-3/16
20406010 3 2-5/16 3-11/16
20406011 4 2-9/16 4-1/16
20406012 5 2-13/16 4-5/16
20406013 6 3-11/16 5-7/16
20406014 7 4-7/16 6-5/16
20406015 8 5-3/16 7-3/16
20406016 9 6-1/16 8-5/16
20406017 10 6-13/16 9-5/16





























Parallel Rramer (ANSI)
order No. D A B
20407001 1/8 7/8 3-1/2
20407002 3/16 1-1/8 4-1/2
20407003 1/4 1-1/2 6
20407004 5/16 1-1/2 6
20407005 3/8 1-3/4 7
20407006 7/16 1-3/4 7
20407007 1/2 2 8
20407008 9/16 2 8
20407009 5/8 2-1/4 9
20407010 11/16 2-1/4 9
20407011 3/4 2-1/2 9-1/2
20407012 7/8 2-5/8 10
20407013 1 2-3/4 10-1/2
20407014 1-1/8 2-7/8 11
20407015 1-1/4 3 11-1/2
20407016 1-3/8 3-1/4 12
20407017 1-1/2 3-1/2 12-1/2
